POM Kiosk Specifications

CSM's Point of Marketing (POM) kiosks consist of state-of-the art hardware and software components.

Hardware

Basic Hardware:
  • Microsoft® Windows® embedded standard OS
  • Intel Atom N450 1.6GHz processor
  • 15" XGA Colour LCD Module
  • Resistive touch screen
  • Stereo speakers
  • USB to USB extension
  • Molded case (different colours available)

Optional Hardware:
  • Swipe-style magnetic stripe reader (3-track)
  • 2D imaging scanner
  • 3" thermal printer with cutter
  • Table-top mount


Software:

The software for the POM kiosks is completely customizable. The following features can be included in or omitted from your software bundle:
  • Multiple attract screens
  • Customized model including graphics and flow of screens:
    • Customizable data collection fields
      e.g:
      • Plain text
      • Email
      • Phone number
      • Postal/zip code
      • Radio buttons
      • Check boxes
      • Scrollable lists
    • Customizable backgrounds
    • Step-by-step screen progression
    • Automated checks for valid and present input – error message appears if check fails
    • Automated checks for internet connectivity and “out of printer paper” statuses
    • Continued local data collection in the event of a loss of internet connectivity - automatic data export when connectivity returns
    • Automated data transfer to CSM’s or client's database
  • Ability to scan and process QR and bar code data through optional hardware
  • Font formatting for printed receipts (includes images)
  • Ability to process magnetic stripe data (from credit cards, loyalty cards, etc.)
  • Automatic updates based on campaign setup and software changes from CSM’s back end
  • Online reporting suite in real time
  • One central database collects data from all registered POM kiosks
  • Local storage of collected data (optional)
  • Local logs transferred to CSM for error monitoring
